ARP690-1 Aluminum Multi-slot Portable
Workstation with 21.5" LCD, 1920x 1080 resolution
|
|
  |
Features
-
Aluminum
Construction with shock absorbing rubber corners
-
21.5" LCD
display support Full HD, 1920x 1080 resolution,
Anti-reflection tempered glass
-
Support Standard
ATX/ EATX MB
-
Offer 7-slot
expansion capability
-
SFX
750W power
supply, 100~240VAC
-
Offer 6x 3.5", 1x 2.5" hidden drive bay, Option: 2x 5.25",
1x 3.5" hidden, 1x 2.5" hidden
-
Industrial
multi-language Keyboard with touchpad
-
Keyboard is
integrated with the portable to allow closing against the
portable for both convenience and protection in
transportation
-
Large handle
provide convenience transportation of the portable with
comfort and ease
-
Trolley case to manage portable
PC with ease
|
Specifications
|
Model No |
ARP690-1 |
|
Motherboard |
Support Standard ATX/
EATX Motherboard
|
|
Slots |
Offer 7 expansion slots |
|
Display |
21.5" LCD display, 1920x 1080
resolution
Anti-reflection tempered
strengthen glass
|
|
Drive bay |
6x 3.5",
1x 2.5" hidden (Option: 2x 5.25", 1x 3.5" hidden, 1x 2.5" hidden) |
|
VGA |
AD conversion board, DisplayPort
interface (Option DVI or VGA) |
|
KB/MS |
Industrial keyboard with
touchpad, Operating life of keys: 8
million cycles
Option KB: CH,
FR,
GR,
IT,
JP,
KR,
PT,
RU,
SP,
UK,
US |
|
Power Supply |
SFX
750W, 100~240VAC, Auto
switch |
|
Construction |
Aluminum Construction with shock
absorbing rubber corners |
|
Speaker |
Built-in amplified 2x 3W speakers |
|
Dimension |
524Wx 372Hx 226D mm |
|
Weight |
14 kgs |
|
Trolley Case |
Padded
Trolley case with wheels |
|
Ordering Information
|
Product No. |
Description |
|
ARP690-121USAP |
21.5" LCD, 7 slots, 6x 3.5", 1x 2.5" drive bay, SFX 750W, DP, Trolley case |
|
ARP690-121USAD |
21.5" LCD, 7 slots, 6x 3.5", 1x 2.5" drive bay, SFX 750W, DVI, Trolley case |
|
ARP690-121USA |
21.5" LCD, 7 slots, 6x 3.5", 1x 2.5" drive bay, SFX 750W, VGA, Trolley case |
|
ARP690-121USBP |
21.5" LCD, 7 slots, 2x 5.25", 1x 3.5", 1x 2.5" drive bay, SFX 750W, DP, Trolley case |
|
ARP690-121USBD |
21.5" LCD, 7 slots, 2x 5.25", 1x 3.5", 1x 2.5" drive bay, SFX 750W, DVI, Trolley case |
|
ARP690-121USB |
21.5" LCD, 7 slots, 2x 5.25", 1x 3.5", 1x 2.5" drive bay, SFX 750W, VGA, Trolley case |
|
|
|
