       Ariesys >>  Products >> Portable Computer >> ARP945-B
ARP945-B                        15" LCD, Core 2 Duo Processors, Multi-slot Portable Battery System
.



Features

  • All-in-one design rugged portable computer

  • Rugged Aluminum Construction with shock absorbing rubber corners

  • Compact Size Lightweight Design

  • Built-in 15" TFT LCD display, 1024x 768 with anti-reflection tempered glass

  • 2x 95W Li-ion battery packs, up to 4 hours battery life

  • Mini-ITX MB, Intel Core 2 Duo T7500 Processors

  • Industrial Keyboard multi-language with touchpad

  • 3x PCI-E (8x) full-length expansion slots, Option: 3x PCI-X or 2x PCI, 1x PCI-E (16x)

  • Built-in 500GB HDD, Support 2x 2.5" removable SATA

  • Dual Gigabit Ethernet Support, 4x SATAII

  • Carrying case to manage portable PC with ease

Industrial Portable Computer Rugged Portable Computer Manufacturer
3x PCI-e (8x) 3x PCI-X

ARP945-B light weights portable systems with integrated battery packs, are robust field portable with 3x PCI-X or 3x PCIe(x8) slots platform built using heavy duty metal to provide tough, go-anywhere unit ideally suitable for harsh/severe environments and mission critical applications.

ARP945-B is designed for harsh environment operations; the LCD screen of the ARP945-B is guarded with a specially treated anti-glare tempered glass for added protection. Every ARP945-B is constructed with easy access to its expansion ports for immediate system upgrade or maintenance. Functional practicality combined with the simple and polished design, the ARP945-B with its extra-rugged construction to sustain bumps and impacted blows, is the most cost-effective, durable and efficient portable solution for your mission critical applications.



Applications: Military, Industrial automation, Digital TV test & analysis, Mobile Computing, Outdoor Computers, video conferencing,

                    E-learning, Speech Technologies, Telemedicine, Portable Workstation, Multimedia, Mission Critical Computing

Specifications
Model No ARP945-B (Battery Packs)
CPU Intel Core 2 Duo T7500 (2.2GHz) Processors
Chipset

Intel Gm45 Chipset + ICH9M

Slot

3x Full-Size PCI-E (x8) slots

Option: 3x full-size PCI-X slots

Option: 2x PCI, 1x PCI-E (x16) slots

Display

15" TFT LCD Monitor, 1024x 768

Anti-reflection tempered strengthen glass

VGA LVDS, GM45 chipset built-in
Memory 2x 2GB Memory
HDD 1x 500GB 2.5", 7200 rpm SATA HDD, Support 2x 2.5" removable SATA
CDROM 1x Slim DVD-RW
Interfaces PS/2 keyboard and mouse, 4x USB, Dual RJ-45 Gigabit LAN
2x COM Port, VGA CRT, audio (3x2)
LAN Dual Intel Gigabit LAN
Audio ICH9M built-in audio HD audio w/ Realtek ALC888 codec
KB/MS

Industrial multi-languages Keyboard/ touchpad

Keyboard layout: CH, FR, GR, JP, KR, RU, UK, US

Power Supply

2x 95W Li-ION battery Packs (Hot-Swappable)

100W AC Adapter, up to 4 hours battery life

Speaker Built-in amplified 2x 3W speakers
Construction Rugged Aluminum Construction with shock absorbing rubber corners
Dimension 412x 330x 184 mm (Wx Hx D)
Weight 9 kgs
Carrying Case Padded carrying case with wheels
Environmental Factors
  Operating Non-Operating
Temperature 0°C~50°C -20°C~60°C
Relative Humidity 10%~90% 10%~95%
Shock

10g, 11ms, half-Sine

30g, 11ms, half-Sine
Vibration

10-500Hz (0.4 Grms)

10-500Hz (1.12 Grms)
Approval CE, FCC, RoHS

ARP945-B (I/O and Battery Packs)

Battery Packs:

  • 2x 95W Li-ION battery Packs (Hot swappable)

  • 100W AC adapter for AC Operation and recharging

  • LCD panel for battery capacity: The LCD display shows battery array fuel gauge, power, current, charge/ discharge state, time to fully charged, time to empty.

  • The battery charge time is about 2 hours if a single battery is attached and 3.5 hours if two battery packs are attached

Ordering Information
Product No. Description
ARP945-XB15USA 15" LCD, T7500 CPU, 2x 2G RAM, 3 PCI-E (x8) slots, 500G HDD, DVD-RW, Battery packs, Carrying case
ARP945-XB15USB 15" LCD, T7500 CPU, 2x 2G RAM, 3 PCI-X slots, 500G HDD, DVD-RW, Battery packs, Carrying case
ARP945-PB15USC 15" LCD, T7500 CPU, 2x 2G RAM, 2PCI, 1 PCI-E(x16) slots, 500G HDD, DVD-RW, Battery packs, Carrying case

Keyboard layout: CH, FR, GR, KR, RU, SP, UK, US

Options
LCD Display



15" TFT LCD display, 1024x 768 resolution
  15.4" TFT LCD display, 1920x 1200 resolution
Power Supply
    ARP945-B: 2x 95W Li-ION battery Packs (Hot-Swappable)
  ARP945: 250W, 100~240 VAC, Auto switch
Processor

Intel Core 2 Duo T7500 (4M Cache, 2.20 GHz, 800 MHz FSB) Processors



Intel Core 2 Duo T9400 (6M Cache, 2.53 GHz, 1066 MHz FSB) Processors
Expansion slot

3x Full-Size PCI-E (8x) Slots
  3x Full-Size PCI-X slots
  2x PCI, 1x PCI-E (16x) full-size
Touch Screen

None
  Touch Screen
Sunlight Readable

None
  Sunlight Readable
Packing List
1 * ARP Slim Rugged Portable Computer 1 * MB Manual & Driver
1 * Carrying case with wheels 1 * Anti-Static Bag
1 * Power Cord 1 * Foam with Box


Applications: Military, Industrial automation, Digital TV test & analysis, Mobile Computing, Outdoor Computers, video conferencing,

                      E-learning, Speech Technologies, Telemedicine, Portable Workstation, Multimedia, Mission Critical Computing.

ARP945-15W      15.4", 1920x 1200 LCD Display



● Rugged Aluminum Construction with shock absorbing rubber corners

● Built-in 15.4” LCD display with tempered glass, 1920x 1200, 262K colors, 170 nits brightness
